| Main |
MS-19R |
MS-25R |
MS-35R |
MS-42R |
MS-50R |
|
Thermal Sensor
|
256 x 192
|
384 x 288
|
384 x 288
|
384 x 288
|
640 x 512
|
|
Objective lens
|
F19 / 1.0 |
F30 / 1.2
|
F42 / 1.2
|
F42 / 1.0
|
F50 / 1.1
|
|
Magnification, x
|
2.5 - 5x
|
1.5 - 6x | 2.0 - 8.0x | 3.0 - 12x | 3.0 - 12x |
|
Field of view (HxV), degrees / m @ 100mtrs
|
9.2 x 6.9 |
14.9 x 11.2
|
10.7 x 8
|
7.5 x 5.7
|
8.8 x 6.6
|
|
Detection range, m
|
900
|
1000
|
1350
|
1800
|
2600
|
|
Sensor
|
|||||
|
Type
|
uncooled Vox
|
uncooled Vox
|
uncooled Vox
|
uncooled Vox
|
uncooled Vox
|
|
Resolution, pixels
|
256 x 192
|
384 x 288
|
384 x 288
|
384 x 288
|
640 x 512
|
|
Pixel Pitch
|
12um
|
17um
|
17um
|
12um
|
12um
|
|
NETD
|
<40mK
|
<35mK
|
<35mK
|
<35mK
|
<35mK
|
|
Frame rate, Hz
|
25
|
50
|
50
|
50
|
50
|
|
Optics
|
|
||||
|
Objective lens
|
F19/1.0 |
F25/1.0
|
F35/1.0
|
F42/1.0
|
F50/1.1
|
|
Magnification, x
|
2.5-5x
|
1.5-6x | 2.0-8.0x | 3.0-12x | 3.0-12x |
|
Field of view (HxV), degrees / m @ 100mtrs
|
9.2 x 6.9 |
14.9 x 11.2
|
10.7 x 8
|
7.5 x 5.7
|
8.8 x 6.6
|
|
Display
|
|
||||
|
Resolution, pixels
|
1280 x 960 LCOS |
1280 x 960 LCOS
|
1280 x 960 LCOS
|
1024 x 768 OLED
|
1024 x 768 OLED
|
|
Thermal Palettes
|
Black Hot, White Hot, Red Hot, Colour |
Black Hot, White Hot, Red Hot, Colour
|
Black Hot, White Hot, Red Hot, Colour
|
Black Hot, White Hot, Red Hot, Colour
|
Black Hot, White Hot, Red Hot, Colour
|
|
Range Performance
|
|
||||
|
Detection range, m (Rabbit)
|
150
|
200
|
300
|
350
|
500
|
|
Detection range, m (Fox)
|
300
|
350
|
500
|
600
|
700
|
|
Detection range, m (Person)
|
900
|
1000
|
1350
|
1800
|
2600
|
|
Detection range, m (Deer)
|
1200
|
1400
|
2000
|
2500
|
3000
|
|
Laser Rangefinder
|
|
||||
|
Safety class for laser equipment according to IEC 60825-1:2014
|
-
|
-
|
-
|
-
|
-
|
|
Wavelength, nm
|
-
|
-
|
-
|
-
|
-
|
|
Max. measuring range, m
|
-
|
-
|
-
|
-
|
-
|
|
Measurement accuracy, m
|
-
|
-
|
-
|
-
|
-
|
|
Min. Measuring Range, m
|
-
|
-
|
-
|
-
|
-
|
|
Reticle
|
|
||||
|
Picture in Picture
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
|
Number of preloaded reticles
|
8 types / 4 colours
|
8 types / 4 colours
|
8 types / 4 colours
|
8 types / 4 colours
|
8 types / 4 colours
|
|
Number of Zero Profiles available
|
4
|
4
|
4
|
4
|
4
|
|
WiFi Connection
|
Yes
|
Yes
|
Yes
|
Yes
|
Yes
|
|
Video Recorder
|
Video & Snapshot
16Gb Internal
|
Video & Snapshot
16Gb Internal
|
Video & Snapshot
16Gb Internal
|
Video & Snapshot
32Gb Internal
|
Video & Snapshot
32Gb Internal
|
|
Environmental Characteristics
|
|||||
|
Degree of protection, IP code (IEC60529)
|
IP66 |
IP66
|
IP66
|
IP66
|
IP66
|
|
Power Supply
|
|
||||
|
Output voltage, V
|
3.0 - 3.7
|
3.0 - 3.7
|
3.0 - 3.7
|
3.0 - 3.7
|
3.0 - 3.7
|
|
Battery type
|
CR123 x2 or RCR123A x2 |
CR123 x2 or RCR123A x2
|
CR123 x2 or RCR123A x2
|
CR123 x2 or RCR123A x2
|
CR123 x2 or RCR123A x2
|
|
Operating time on battery pack (at t=22°C), h *
|
6
|
4
|
4
|
4
|
4
|
|
External power supply, V
|
5V (USB Type-C)
|
5V (USB Type-C) |
5V (USB Type-C)
|
5V (USB Type-C)
|
5V (USB Type-C)
|
|
Connections and Compatibilities
|
|
||||
|
Max. recoil power on firearm
|
Shock Proof to 1000G (300 Win Mag)
|
Shock Proof to 1000G (300 Win Mag)
|
Shock Proof to 1000G (300 Win Mag)
|
Shock Proof to 1000G (300 Win Mag)
|
Shock Proof to 1000G (300 Win Mag)
|
|
Mounting brackets on firearm
|
Full Picatinny rail (0 MOA) |
Full Picatinny rail (0 MOA)
|
Full Picatinny rail (0 MOA)
|
Full Picatinny rail (0 MOA)
|
Full Picatinny rail (0 MOA)
|
|
Weight & Size
|
|
||||
|
Dimensions, mm
|
186 x 60 x 60
|
180 x 60 x 60
|
195 x 60 x 60
|
195 x 61 x 61
|
216 x 61 x 61
|
|
Weight, kg
|
0.38
|
0.41
|
0.42
|
0.42
|
0.51
|
|
Warranty
|
3 years
|
3 years
|
3 years
|
3 years
|
3 years
|
|
Trade Data
|
|
||||
|
SKU (Model #)
|
MS-19R
|
MS-25R
|
MS-35R
|
MS-42R
|
MS-50R
|
